PERANCANGAN SISTEM MONITORING DAN PROTEKSI GANGGUAN INTERNAL BERBASIS IoT PADA CAPACITOR BANK
DOI:
https://doi.org/10.26740/jte.v15n3.p249-256Keywords:
capacitor bank, ESP32, Internet of Things, monitoring system, protection relayAbstract
Capacitor banks are used in industrial electrical systems to improve power factor and voltage stability. However, internal disturbances such as overvoltage, undervoltage, overcurrent, and overheating can reduce reliability and increase the risk of equipment damage. This study develops an Internet of Things (IoT)-based monitoring and protection system for capacitor banks using an ESP32 microcontroller. The prototype integrates a ZMPT101B AC voltage sensor, ACS712 AC current sensor, DHT22 temperature and humidity sensor, relay, buzzer, LCD, and Blynk dashboard. The ESP32 reads the sensors in real time, compares the measurements with predefined thresholds, and activates alarm and relay protection when abnormal conditions are detected. Testing showed that the system could monitor voltage, current, and temperature continuously, visualize data locally and remotely, and support automatic protection against internal electrical faults. During normal observation, voltage ranged from 220.05 V to 224.62 V, current from 10.56 A to 63.73 A, and temperature from 28.96 °C to 35.63 °C. The proposed system provides practical remote supervision and early fault response for capacitor bank panels.
Downloads
References
[1] R. S. W. Widagdo, G. Budiono, and M. I. Novianto, “Analysis of capacitor bank installation for power quality improvement at PT. Sunrise Steel,” Wahana, vol. 75, no. 2, 2023.
[2] I. Surya, A. Maulana, and R. Prasetyo, “Sistem monitoring beban listrik dan perbaikan faktor daya menggunakan PZEM004T berbasis IoT,” Jurnal Informatika dan Teknik Elektro Terapan, vol. 3, no. 3, 2023.
[3] A. Jaenul, M. Manfaluthy, Y. Pramodja, and F. Anjara, “Capacitor bank performance and power quality evaluation in low-voltage distribution systems,” Journal of Electrical Engineering and Technology, 2023.
[4] A. Setiawan, R. Pratama, and D. Kurniawan, “Smart energy monitoring system using ESP32 and MQTT for real-time electrical parameter tracking,” International Journal of Electrical and Computer Engineering, 2022.
[5] T. Sutikno, A. Hakim, and M. F. Akbar, “Monitoring tegangan dan arus pada panel surya menggunakan IoT,” Majalah Ilmiah Teknologi Elektro, vol. 22, no. 1, 2023.
[6] I. Irawati, M. T. Amien, E. Sumarno, and F. Rosyadi, “Prototype monitoring suhu dan kelembapan pada kubikel 20 kV berbasis IoT,” Transmisi, vol. 25, no. 3, 2023.
[7] A. B. Arief, “Rancang bangun sistem kendali otomatis dan monitoring suhu dan kelembapan pada rumah burung walet berbasis Blynk,” Jurnal Informatika dan Teknik Elektro Terapan, vol. 12, no. 2, 2024.
[8] M. G. Arkhan and Z. R. Saputra, “Air quality monitoring system based Internet of Things,” Brilliance: Research of Artificial Intelligence, vol. 4, no. 2, 2023.
[9] H. S. Hakki, “ESP8266 and ESP32 series of SoC microcontrollers,” Programmable Smart Microcontroller Cards, 2021.
[10] A. Saputra, H. Khumaini, and A. Azkiya, “Perancangan alat monitoring arus pada circuit breaker dengan sensor ACS712 menggunakan tampilan LCD,” Informatika, vol. 14, no. 2, 2023.
[11] L. H. Laisina, “Leak current detector in low voltage network system using ZMPT101B sensor based on the Internet of Things,” International Journal of Multidisciplinary Science and Arts, vol. 2, no. 1, 2023.
[12] R. J. Syahputra, “Monitoring the temperature and humidity air in the room using a sensor IoT-based DHT-11,” Journal of Artificial Intelligence Engineering and Applications, vol. 3, no. 1, 2023.
[13] R. Ramadhani, A. Wijaya, and D. R. Nugroho, “Monitoring suhu panel distribusi menggunakan sensor digital berbasis mikrokontroler,” Jurnal Teknik Elektro dan Komputer, 2022.
[14] M. Akbari, “Interfacing ZMPT101B voltage sensor with Arduino,” ElectroPeak, 2021.
